Data Matrix Code Tape
- 1-, 2-, or 4-square code height
- Durable - resistant to oils and alcohols
- X,Y absolute positional feedback, 0.1 mm resolution
- Adhesive backing for easy installation
PosiTrack Laminate Code Rail
- Built to customer-specified lengths
- Positional stickers every 1000 counts
- High mechanical flexibility
- Cost effective
SmartRunner
- Unique combination of light section technology and 2-D vision sensor with integrated LEDs opens up a variety of new applications
- Application-specific sensors preconfigured and calibrated based on the application
- Transformation of complex measuring data into simple digital signals for fast and easy integration
- Easy installation due to parameterization via Data Matrix control codes or pushbutton teach-in
- Light section technology provides reliable measuring on any material regardless of surface color or contour
PXV and safePXV Read Head
- 100 mm reader-to-tape separation
- Unique colored code tape for safePXV to allow SIL 3 / PL e rating
- 0.1 mm absolute position in X and Y axis, 8 m/s max speed (PXV) and 6 m/s max speed (safePXV)
- Event markers to identify starts, stops, zones, and ID
- EtherNet/IP, SSI, RS-485, PROFINET, CANopen (PXV), and PROFIsafe (safePXV)
- Reliable position feedback with damaged code tape or 75 mm gaps
PosiTrack Stainless Steel Code Rail
- 100% stainless steel construction
- Built to customer-specified lengths
- Mechanically durable
- Excellent corrosion and moisture immunity
PosiTrack WCS2B Read Head, Trolley, & Track
- For the dirtiest, dustiest environments
- Trolley-track system provides wide movement tolerance
- Application - Overhead crane positioning and skew prevention
- Application - Galvanizing processes
PosiTrack WCS3B Read Head
- For use with WCS3 coded rail
- +/- 0.4 mm resolution and 12.5 m/s maximum speed
- Integral RS-485, SSI, and CANopen models
- 1,032 ft maximum continuous travel
PGV and safePGV Read Head
- Three automation functions in one sensor
- Unique colored code tape for safePGV to allow SIL 3 / PL e rating
- Absolute position code tape and colored lane guidance for AGVs
- 100 mm reader-to-tape separation
- 0.2 mm absolute position in X and Y axis, 360 degree angular feedback for turns
- Control codes initiate starts, stops, speed control
- Reliable position feedback with damaged code tape or 75 mm gaps
R2000 Laser
- 2D distance measurement with PRT
- Gapless, 360 degree measuring angle - Razor sharp scan plane
- Extremely high angular resolution and positioning accuracy
- Small, compact design with wrap-around LED display
R2100 LED
- 2-D distance measurement with PRT
- Broad, 88 degree measuring angle - wide-area scan plane
- Ultra-IR LEDs guarantee powerful performance and long lifetime
- Rugged design - no moving parts for added durability
PosiTrack Outdoor Housing
- Standard WCS in an IP69K housing
- Designed for harsh outdoor applications
- Translucent protective housing allows LED indication
R2300 LiDAR
- Measuring method PRT
- High angle resolution
- Measuring angle of 100 degrees
- Collision avoidance and navigation
- Detects small structures and contours
3-D Stereo Sensor
- User-friendly operating software, ViSolution
- Measurement data preprocessing
- Gigabit-Ethernet (GigE) interface
- Simple and fast mounting
3-D Time-of-Flight Sensor
- DuraBeam technology
- C# API
- Gigabit-Ethernet (GigE) interface
- Resolution 640 x 480 pixels
- Detection range 400 mm to 7500 mm
Industrial Event Camera
- Web interface for easy access
- Trigger video/image capture via UDP, REST API, or hardware
- Mounting 0.5 m to infinite
- Timestamped events
